ABC Dry Powder TYPE FIRE EXTINGUISHER
WEIGHT
- 1kg
- 2kg
- 4kg
- 6kg
- 9kg
This is a premium range of appliances available in ABC Powder, pressurised with dry nitrogen gas/Co2 Cartridge. The contents are expelled by the release of pressure stored inside the body. The inbuilt pressure gauge indicates its readiness for use. ABC powder is one of the most versatile and highly effective agents suitable to combat fires involving wood, inflammable liquids, gases and electrical wiring. This extinguisher knocks down fire by beating and displacement of air.
| 1 kg | 2 kg | 4 kg | 6 kg | 9 kg | 9kg (Cartridge Type) | |
|---|---|---|---|---|---|---|
| Fire Rating | 1A:21B | 1A:21B | 2A:55B | 3A:89B | 4A:144B | 4A:144B |
| Discharge Time | 8 sec | 8 sec | 18 sec | 24 sec | 31 sec | 31 sec |
| Total Height | 305 MM | 360 MM | 485 MM | 485 MM | 570 MM | 570 MM |
| Diameter | 86 MM | 108 MM | 130 MM | 160 MM | 175 MM | 175 MM |
| Charged Weight | 2.2kg | 3.5kg | 6.5kg | 8.5kg | 12.5kg | 13.5kg |
| Operating Temperature | –10°C to +55°C | –10°C to +55°C | –10°C to +55°C | –10°C to +55°C | –10°C to +55°C | –10°C to +55°C |
| Service Pressure | 15 bar | 15 bar | 15 bar | 15 bar | 15 bar | 15 bar |
| Maximum Service Pressure | 18 bar | 18 bar | 18 bar | 18 bar | 18 bar | 18 bar |
| Test Pressure | 35 bar | 35 bar | 35 bar | 35 bar | 35 bar | 35 bar |
| Jet Range | 2 metre | 2 metre | 3 metre | 4 metre | 5 metre | 5 metre |
